Kromschroder UVS 10D2 UVS 10D0G1 UVS 10D1G1 UV Flame Detector Flame Monitoring for Industrial Burners
Collected in wish list
- Description
- Specification
- Q&A
- Customer Reviews
| item | value |
| Application | Industrial |
| Material | Plastic |
| Place of Origin | Germany |
| Motor Type | Universal |
| Model Number | UVS10D0G1 |
| Brand Name | Hokod |
The main brands sold by our company are: Honeywell, Kromschroder, Fireye, MAXITROL, SIEMENS, OMRON, Durag, DUNGS, Elektrogas, Azbil, COFI, MADAS, Fujifilm, Eurotherm, WEST, LAM TEC, Fisher
Main products are :DCS, SIS system, transmitter (temperature transmitter, pressure transmitter, differential pressure transmitter), temperature control instrument, carbon control meter, combustion safety products: flame detector, flame controller, solenoid valve, pressure switch, actuator, transformer,
1. who are we?
We are based in Shanghai, China, start from 2018,sell to Domestic Market(87.00%),South Asia(1.00%),Eastern Asia(1.00%),North America(1.00%),South America(1.00%),Oceania(1.00%),Western Europe(1.00%),Southern Europe(1.00%),Central America(1.00%),Northern Europe(1.00%),Africa(1.00%),Eastern Europe(1.00%),Mid East(1.00%),Southeast Asia(1.00%). There are total about 5-10 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
PLC, Gas detector, Temperature control meter, Burner accessories, Building automatic control instrument
4. why should you buy from us not from other suppliers?
Our company mainly engaged in Honeywell DCS and SIS system.Honeywell transmitter. Honeywell, Omron, Fuji temperature control instrument.combustion safety control products: Honeywell, Kromschroder, Siemens, Fireye, Maxitrol.adequate inventory, original auth
5. what services can we provide?
Accepted Delivery Terms: -;
Accepted Payment Currency: USD,CNY;
Accepted Payment Type: T/T;
Language Spoken: English,Chinese
Model Designation (UVS 10D×G1)
UVS: UV Sensor (Ultraviolet Sensor)
10: 10 Series
D: Equipped with Quartz Glass Heat Shield (High-Temperature Resistant)
0/1/2: Interface and Cooling Configuration
0: Rp 1/2" Internal Thread; No Cooling Air Port
1: Rp 1/2" Internal Thread; With Cooling Air Port
2: 1/2" NPT Internal Thread; With Cooling Air Port
G1: Electrical Interface — M20 Cable Gland
I. UVS 10D0G1
Replacement for: Older UVS 6 Model
Interface: Rp 1/2" Internal Thread; No Cooling Air Port
Electrical Connection: M20 Cable Gland
Features: Compact structure; suitable for small burners and environments with moderate ambient temperatures.
Weight: Approx. 0.28 kg
II. UVS 10D1G1
Interface: Rp 1/2" Internal Thread; With Cooling Air Port (Allows connection of cooling air; high-temperature resistant).
Electrical Connection: M20 Cable Gland
Features: Includes cooling capability; suitable for high-temperature furnaces/kilns, pilot flame monitoring, and main flame monitoring.
Weight: Approx. 0.28 kg
III. UVS 10D2
Replacement for: Older UVS 8 Model (Requires replacement of connection cable).
Interface: 1/2" NPT Internal Thread; With Cooling Air Port.
Electrical Connection: M20 Cable Gland
Features: NPT threading is compatible with North American standards and certain export equipment; high-temperature resistant with strong interference immunity.
Weight: Approx. 0.28 kg
General Technical Specifications (Identical for all three models)
UV Tube: P578
Spectral Range: 190–270 nm
Peak Sensitivity: 210 ±10 nm
Minimum Signal: 1 μA DC
Tube Lifespan: Approx. 10,000 hours
Ambient Temperature: -40°C to +80°C
Housing: Aluminum alloy; integrated heat shield
Protection Class: IP65
Selection Guide
UVS 10D0G1: Small burner, ambient temperature environment, no cooling required
UVS 10D1G1: High-temperature furnace, cooling required, standard Rp 1/2" thread
UVS 10D2: NPT thread, export equipment, high-temperature applications requiring cooling
