USA Honeywell Electric Ball Valve Actuator MVN7510 MVN7234 Original 1 Year Warranty Boiler Parts

MVN7510

Rated Torque: 10 Nm

Operating Voltage: AC/DC 24V

Control Signal: 0–10V Analog Modulation

Protection Class: IP54

Applicable Media: Water, Air

Operating Mode: Proportional Control, Position Hold on Power Loss

The MVN7510 is a compact, modulating electric actuator from Honeywell, designed to be compatible with a wide range of HVAC ball valves. It features sensitive response and quiet operation. Equipped with built-in overload protection, it offers easy installation and high adaptability. Widely utilized in automation systems for central air conditioning, building fresh air ventilation, and hydronic underfloor heating, this actuator delivers stable, durable performance; it precisely controls fluid flow rates, thereby significantly enhancing energy efficiency in building temperature control.

MVN7234

High-Torque HVAC Automation Component

Rated Torque: 34 Nm

Operating Voltage: AC/DC 24V

Control Signal: 0 (2) – 10V Analog Modulation

Protection Class: IP54

Rotation Angle: 95° ± 3° (Mechanically Adjustable)

Run Time: 95–110s (50Hz)

Power Consumption: 10 VA / 5 W

Operating Temperature: -20°C to +60°C

Features: Overload Protection, Position Hold on Power Loss, External Auxiliary Switch Capability

Weight: Approx. 1.59 kg

The MVN7234 is a high-torque modulating electric actuator from Honeywell, designed to pair with the VBA16P/F series of ball valves. It is specifically engineered for fluid control applications within medium-to-large diameter HVAC and building automation systems. Featuring a 24V power supply and 0–10V proportional control, the unit delivers stable response and quiet operation. It includes built-in overload protection and a "position hold" function; in the event of a signal loss, the actuator maintains its current valve position, thereby ensuring system safety. The unit comes with a pre-installed mounting bracket to simplify on-site commissioning. Widely utilized in central air conditioning systems, chilled/hot water loops, and industrial fluid control scenarios, this actuator offers a robust 34 Nm torque output—compatible with DN65 through DN150 ball valves—delivering durability and reliability that significantly enhances energy efficiency in building automation systems.
