White Rodgers 36J41K-200 36J22-214 36J22-216 Gas Solenoid Valve Boiler 24V 220V Stock
Collected in wish list
- Description
- Specification
- Q&A
- Customer Reviews
Original and new | Original and new |
Place of Origin | USA |
Brand Name | White Rodgers |
Model Number | 36j22-214 36j41k-200 |
Product name | Solenoid Valve |
Warranty | 1 Year |
Point of origin | USA/MEXICO |
Packaging Details | 1pcs/box |
Use place | burner |
Inventory quantity | >200PCS |
We usually quote within 24 hours after we get your inquiry.If you are very urgent to get the price, please call us or tell us in
your email so that we will regard your inquiry priority.
2.How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. If you just need a blank sample to check the design and paper quality, we will provide you sample for free, as long as you afford the express freight.
3.How long can I expect to get the sample?
After you pay the sample charge and send us confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3-5 workdays.
You can use your own express account or prepay us if you do not have an account.
4. How long does the whole procedure being worked out?
After you place a order,the production handling time is about 45-60 days.
We need 15 days to prepare all the stuff then 30 days for manufacturing.
5.What about the transportation and delivery date?
Normally we use shipment to transprot the goods.It is about 25-40 days.It also denpends on which coutry and port you are.It could be shorter if you need to send the goods like Asian.
If there are some emergencies we can send the goods via air express, as long as you afford the traffic expense.
6.What is your term of delivery?
We accept EXW, FOB Shenzhen or FOB Guangzhou. You can choose the one which is the most convenient or cost effective for you.
7.What about the lead time for the mass production?
Honestly, it depends on the order quantity and the season you place the order.
8.Can we print our logo/website/company name on products?
Yes, please advise the size and Pantone Code of the logo.
9.What's the lead time for regular order?
14-21 days for order quantity lower than 5000pc; For more quantity, usually 30 days.
10.Do you inspect the finished products?
Yes, each step of production and finished products will be came out inspection by QC department before shipping.
The Emerson White-Rodgers 36J Series Gas Control Valve is a compact, multi-functional combination valve designed for use in the Hot Surface Ignition (HSI) and Direct Spark Ignition (DSI) systems of wall-mounted boilers, water heaters, and various heating appliances.
I. Model 36J41K-200 (230V, Fast-Opening Type)
Application: A 230V, single-stage, fast-opening gas valve suitable for combustion equipment compliant with European standards.
Electrical: 230V / 50–60Hz, 6.9VA
Pressure: Max. pressure drop 50 mbar; Overpressure range 6–15 mbar
Type: Class B+C Valve (Class 2)
Environmental: −40°C to +70°C
Connections: DN15 (1/2"); features built-in pressure test ports and 1/4" quick-connect terminals
Mounting: Can be installed at any angle
II. Model 36J22-214 (24V, Fast-Opening Type — Most Popular Model)
Application: A 24V, single-stage, fast-opening valve; the primary model used in residential wall-mounted boilers and water heaters. Electrical: 24 VAC, 50/60 Hz
Gas Type: Natural Gas / LP Gas (includes LP conversion kit)
Connections: 1/2" NPT Inlet/Outlet, with built-in strainer
Pressure: Natural Gas 2.5–5.0" W.C.; LP Gas 7.0–12.0" W.C.
Flow Rate: Natural Gas 140,000 BTU/h; LP Gas 226,800 BTU/h
Features: Fast-opening, redundant safety, built-in pressure taps, silent operation design
III. 36J22-216 (24V Fast-Opening, High-Flow Version)
Application: A high-flow/high-pressure upgrade of the 36J22-214 model, suitable for high-power equipment.
Electrical: 24 VAC (identical to the 36J22-214)
Connections: 1/2" NPT (select versions available with 3/4" NPT)
Pressure: Regulation range identical to the 36J22-214; features a higher maximum pressure rating.
Flow Rate: Increased by approximately 15–20% compared to the 214 model; suitable for equipment rated at 200,000 BTU/h and above.
Key Differences: Optimized internal flow channels, slightly higher coil power, suitable for high-altitude and high-pressure operating conditions.
